Product Parameters
Dimensions
|
Size: A
|
200
|
|
Size: B
|
135
|
|
Size: C
|
49 |
|
Size: D
|
155
|
|
Weight(kg) |
3.0/3.15 |
|
Construction |
Gear Drive |
|
Rated Voltage (DC) |
36V/48V |
|
Rated Power (W) |
250/350 |
|
RPM |
105/115 |
|
Max Torque (Nm) |
80/100 |
|
Max Efficiency（%） |
≥80% |
|
Sensor |
Integrated Torque & Cadence Sensor |
|
Coaster Brake |
Option |
|
Construction |
Uart/CAN |
|
Shaft Standard |
JIS |
|
Noise Grade (dB) |
<55 |
|
Color |
Black |
|
OperationTemperature(°C) |
-20~55 |
|
e-Brake |
Yes |
|
Gear Sensor |
Yes |
|
Light Drive Capacity |
6V3W/12V6W(Max) |
|
Certifications |
CE/EN 15194/RoHS/REACH |
|
Tests |
Waterproof: IPX5 |
|
|
Salt Spray Test Standard(h): 96h |
|
Usage |
eCity/eTrekking |
