[VIP The 1 year ] Index:1
| Body | ||
| Length | 4900 | (mm) |
| Width | 2100 /2850 (Max) | (mm) |
| High | 2650/ 4900 (Max) | (mm) |
| Weight | 2900 | (kg) |
| Engine | ||
| Model | Kubota | |
| Type | Vertical 4 cycle liquid cooled diesel | |
| Engine | 29.8(40) & 44.74 (60) | (KW(HP) |
| Rated Engine Speed | 2700 | (RMP) |
| Displacement | 2.746 | (L) |
| Transmissions | HST | |
| Battery Power | 150 | (CCA) |
| Fuel Tank Capacity | 40 | (L) |
| Cutting | ||
| Deep adjustment | Around 15 | (cm) |
| Cuter bar range | 30~40 | (cm) |
| Grain Tank | ||
| Height Adjustment | Hydraulics | |
| Capacity | 800 | (L) |
| Harvesting Capacity Acer / Hour | 0.68 (TAIWAN) | |
| * 1 HP = 745.7W = 0.7457KW. | ||
*Appearance and specifications are subject to change without notice for product improvement. YCM reserves the right of final explanation
Options：
Cab、LED、Reversing display
