ITEM
|
SPECIFICATION
|
|
WEIGHT CAPACITY
|
160kgs(352 lbs) |
|
SEATGTYPE/SIZE
|
20"
|
|
DRIVE WHEEL
|
410mmx100mm (16"x4")
|
|
FRONT CASTER |
360mmx90mm (14"x3.5")
|
|
REAR CASTER |
-
|
|
MAX SPEED
|
15KPH(9.5MPH)
|
|
BATTERY |
12V 80Ah x 2 Pcs
|
|
BATTERY RANGE
|
50Km(32Miles)
|
|
CHARGER TYPE
|
8Amp,Off Board 120/240 Volt, /50/60Hz
|
|
ConTROLLER TYPE
|
Dynamic Rhino 160 Amp
|
|
MOTOR TYPE
|
4100rpm 1300W 21:1
|
|
LENGTH
|
1580mm(62")
|
|
WIDE
|
730mm(29")
|
|
HEIGHT
|
1350mm(53")
|
|
SEAT WIDTH
|
508mm(20")
|
|
SEAT HEIGHT
|
711mm(28")
|
|
SEAT DEPTH
|
460mm(18")
|
|
BACK HEIGHT
|
698mm(27.5")
|
|
WHEEL base
|
1000mm(39")
|
|
FOOTRESTS
|
460mm(18")
|
|
WEIGHT:W/BATTERY
|
151kgs(332lbs)
|
|
W/0 BATTERY
|
101kgs(222 lbs)
|
|
GROUND CLEARANCE
|
150mm(6")
|
|
SUSPENSION
|
Full
|
|
SPECIALITY
|
-
|
|
TURNING RADIUS
|
1260mm(49.5")
|
|
SAFE CLIMBING |
12 degree
|
|
20'
|
20 SET
|
|
40'
|
42 SET
|
|
40'HQ
|
-
|
