ITEM
|
SPECIFICATION
|
|
WEIGHT CAPACITY
|
135Kgs(300lbs)
|
|
SEATGTYPE/SIZE
|
18" A2
|
|
DRIVE WHEEL
|
270mmx100mm(11"x4")
|
|
FRONT CASTER |
270mmx100mm(11"x4")
|
|
REAR CASTER |
-
|
|
MAX SPEED
|
10KPH(6.3MPH)
|
|
BATTERY |
12V 34Ah x 2pcs or 12V 50Ah x 2pcs (Optional)
|
|
BATTERY RANGE
|
30km(18Miles) /45km(28Miles)
|
|
CHARGER TYPE
|
5Amp,Off Board120/240 Volt, 50/60 Hz
|
|
ConTROLLER TYPE
|
Dynamic Rhino 110Amp
|
|
MOTOR TYPE
|
4000rpm 500W 25:1
|
|
LENGTH
|
1270mm(50")
|
|
WIDE
|
670mm(26")
|
|
HEIGHT
|
1030mm(40.5")
|
|
SEAT WIDTH
|
460mm(18")
|
|
SEAT HEIGHT
|
460mm(18")
|
|
SEAT DEPTH
|
460mm(18")
|
|
BACK HEIGHT
|
440mm(17.3")
|
|
WHEEL base
|
880mm(34.6")
|
|
FOOTRESTS
|
-
|
|
WEIGHT:W/BATTERY
|
105kgs(231 lbs)
|
|
W/0 BATTERY
|
77kgs(170lbs)
|
|
GROUND CLEARANCE
|
100mm
|
|
SUSPENSION
|
FULL
|
|
SPECIALITY
|
-
|
|
TURNING RADIUS
|
980mm
|
|
SAFE CLIMBING |
-
|
|
20'
|
24 SET
|
|
40'
|
50 SET
|
|
40'HQ
|
78 SET
|
