ITEM
|
SPECIFICATION
|
|
WEIGHT CAPACITY
|
185kgs(400 lbs)
|
|
SEATGTYPE/SIZE
|
20" A2
|
|
DRIVE WHEEL
|
360mmx100mm(14"x6.5")
|
|
FRONT CASTER |
330mmx100mm(13"x4")
|
|
REAR CASTER |
-
|
|
MAX SPEED
|
13KPH(8MPH)
|
|
BATTERY |
12V 50Ah x 2pcs or 12V 62Ah x2pcs(Optional)
|
|
BATTERY RANGE
|
35km(22Miles)/45km(28Miles)
|
|
CHARGER TYPE
|
5Amp,Off Board 120/240 Volt, 50/60 Hz
|
|
ConTROLLER TYPE
|
DYNAMIC RHINO 110Amp
|
|
MOTOR TYPE
|
700W 4-POLE MOTOR
|
|
LENGTH
|
1570mm(62")
|
|
WIDE
|
800mm(31.5")
|
|
HEIGHT
|
1350mm(53")
|
|
SEAT WIDTH
|
510mm(20")
|
|
SEAT HEIGHT
|
460mm(18")
|
|
SEAT DEPTH
|
480mm(19")
|
|
BACK HEIGHT
|
770mm(30")
|
|
WHEEL base
|
970mm(38")
|
|
FOOTRESTS
|
-
|
|
WEIGHT:W/BATTERY
|
113kgs(249lbs)
|
|
W/0 BATTERY
|
85(kgs(187lbs)
|
|
GROUND CLEARANCE
|
120mm(4.7")
|
|
SUSPENSION
|
FULL
|
|
SPECIALITY
|
-
|
|
TURNING RADIUS
|
1160mm (45.6")
|
|
SAFE CLIMBING |
-
|
|
