ITEM
|
SPECIFICATION
|
|
WEIGHT CAPACITY
|
135kgs(300 lbs)
|
|
SEATGTYPE/SIZE
|
18"
|
|
DRIVE WHEEL
|
240mmx75mm(9.5"x3")
|
|
FRONT CASTER |
240mmx75mm(9.5"x3")
|
|
REAR CASTER |
Option
|
|
MAX SPEED
|
8KPH(5MPH)
|
|
BATTERY |
12V 22Ah x 2pcs
|
|
BATTERY RANGE
|
20km(12.5miles)
|
|
CHARGER TYPE
|
2Amp,Off Board 120/240 Volt, 50/60 Hz
|
|
ConTROLLER TYPE
|
P&G S-Drive 70Amp
|
|
MOTOR TYPE
|
4400rpm 400W 17.7:1
|
|
LENGTH
|
1070mm(42")
|
|
WIDE
|
580mm(22.8")
|
|
HEIGHT
|
915mm(36")
|
|
SEAT WIDTH
|
410mm(16")
|
|
SEAT HEIGHT
|
400mm(15.7")
|
|
SEAT DEPTH
|
410mm(16")
|
|
BACK HEIGHT
|
350mm(13.8")
|
|
WHEEL base
|
815mm(32")
|
|
FOOTRESTS
|
-
|
|
WEIGHT:W/BATTERY
|
58Kgs(128lbs)
|
|
W/0 BATTERY
|
48kgs(105lbs)
|
|
GROUND CLEARANCE
|
70mm(2.8")
|
|
SUSPENSION
|
Rear
|
|
SPECIALITY
|
-
|
|
TURNING RADIUS
|
1200mm(47")
|
|
SAFE CLIMBING |
-
|
|
20'
|
80 SET
|
|
40'
|
-
|
|
40'HQ
|
168 SET
|
