ITEM
|
SPECIFICATION
|
|
WEIGHT CAPACITY
|
160kgs(350lbs)
|
|
SEATGTYPE/SIZE
|
20" A2
|
|
DRIVE WHEEL
|
330mmx120mm(13"x5")
|
|
FRONT CASTER |
330mmx100mm(13"x4")
|
|
REAR CASTER |
-
|
|
MAX SPEED
|
13KPH(8MPH)
|
|
BATTERY |
12V 62Ah x 2pcs or 12V 80Ah x2pcs(Option)
|
|
BATTERY RANGE
|
35km(22miles)/45km(28miles)
|
|
CHARGER TYPE
|
5Amp,Off Board
|
|
ConTROLLER TYPE
|
DYNAMIC RHINO 110Amp
|
|
MOTOR TYPE
|
700W 4-POLE MOTOR
|
|
LENGTH
|
1400mm(55")
|
|
WIDE
|
700mm(27.5")
|
|
HEIGHT
|
1360mm(53.5")
|
|
SEAT WIDTH
|
510mm(50")
|
|
SEAT HEIGHT
|
460mm(18")
|
|
SEAT DEPTH
|
480mm(18.9")
|
|
BACK HEIGHT
|
750mm(30")
|
|
WHEEL base
|
1025mm(40")
|
|
FOOTRESTS
|
-
|
|
WEIGHT:W/BATTERY
|
135kgs(220lbs)
|
|
W/0 BATTERY
|
95kgs(209 lbs)
|
|
GROUND CLEARANCE
|
80mm(3")
|
|
SUSPENSION
|
FULL
|
|
SPECIALITY
|
-
|
|
TURNING RADIUS
|
1280mm(50")
|
|
SAFE CLIMBING |
-
|
|
20'
|
20 SET
|
|
40'
|
46 SET
|
|
40'HQ
|
69 SET
|
