ITEM
|
SPECIFICATION
|
|
WEIGHT CAPACITY
|
115kgs(250 lbs)
|
|
SEATGTYPE/SIZE
|
18"
|
|
DRIVE WHEEL
|
200mmx75mm (8" x 3")
|
|
FRONT CASTER |
200mmx50mm (8"x2")
|
|
REAR CASTER |
65mmx25mm (2.6" x 1")
|
|
MAX SPEED
|
6KPH (3.8 MPH)
|
|
BATTERY |
12V 12Ah x 2 Pcs
|
|
BATTERY RANGE
|
15km (9.3 Miles)
|
|
CHARGER TYPE
|
5Amp,Off Board120/240 Volt, 50/60 Hz
|
|
ConTROLLER TYPE
|
Dynamic Rhino 70 Amp
|
|
MOTOR TYPE
|
4700rpm 270W 21:1
|
|
LENGTH
|
1040mm(41")
|
|
WIDE
|
535mm(21")
|
|
HEIGHT
|
840mm(33")
|
|
SEAT WIDTH
|
432mm(17")
|
|
SEAT HEIGHT
|
500mm(19.7")
|
|
SEAT DEPTH
|
381mm(15")
|
|
BACK HEIGHT
|
381mm(15")
|
|
WHEEL base
|
760mm(30")
|
|
FOOTRESTS
|
370mm(14.5")
|
|
WEIGHT:W/BATTERY
|
40kgs(88 lbs)
|
|
W/0 BATTERY
|
31kgs(68 lbs)
|
|
GROUND CLEARANCE
|
50mm(2")
|
|
SUSPENSION
|
-
|
|
SPECIALITY
|
-
|
|
TURNING RADIUS
|
860mm(34")
|
|
SAFE CLIMBING |
-
|
|
20'
|
-
|
|
40'
|
-
|
|
40'HQ
|
-
|
