Product Specifications/Features :
1. Specifications:
. Flow Rate:
. Clean Water: 4Gpm/16Lpm
. DI, R. O. Water: 5Gpm/20Lpm
. Voltage Available:
. 100 ~ 120V
. 220 ~ 240V
. 50/60Hz
. UV Germicidal Lamp: 24W x 1 (model: UVC-D450T5 or
UVC-S450T5)
. Ballast: 24W x 1
. Dimension: 64 x 512mm
. Inlet/Outlet Size: 1/2 inch NPT
. Max. Working Pressure: 125 PSI
. Chamber/Housing: No. 304 stainless steel
. Quartz Sleeve Model No. SQ230500
. Lamp Failure Warning System: LED + alarm
. Lamp Average Life: 9,000hrs
2. Features:
. High quality quartz lamp and sleeve keep high
output of UV emit.
. Quick and simple installation
. Long service life saves your money.
. Polished stainless steel reactor chambers strong the
UV reflection.
. Visual LED display indicator and audible alarm for
lamp failure
. The most natural way to protects your water safely
. Easy lamp replacement and maintenance
. Wide application, able to be used in various water
treatment areas
. Neither add any chemical complexes nor change the
taste and odor of the water, it will not remove any
beneficial minerals in the water.
. It is able to kill 99. 9% destruction of bacteria and
virus under the standard water quality and flow.
