Radiolucent Coverage
|
Unobstructed imaging length of 1070*360mm and 100% C-Arm access achieved via reverse patient orientation or sliding function.
|
|
Sliding (ST-1751/1752, ST-1551/1552 models)
|
Large sliding tabletop with a total of 18" (460mm) providing maximum radiological access without patient reversing.
|
|
Patient Orientation Recognition
|
With one push of a remote controller button, the table movements will changeover from normal to reverse orientation.
|
|
Motorized Kidney Elevator
|
Motorized kidney elevator is made of radiolucent material and facilitates lateral operations.
|
|
Electric Powered Leg Section (ST-1701/1751, ST-1501/1551 models)
|
One solid leg section is powered and bends downward to 105°, reducing the burden on the surgical team to remove the leg. This leg is also detachable manually to allow excellent surgical access and more legroom to surgeons during procedures.
|
|
Auto-Level Function
|
One push button of the hand controller that correspond to zero position of the tabletop.
|
|
Chair Position Memory
|
Chair position may be called by pressing the CHAIR button on the hand controller.
|
|
Stainless Steel Enclosure
|
Stainless steel, frame, telescoping shrouds, side rails and base cover are easily cleaned and resist oxidization and chemicals corrosion. The base cover and shrouds are a two-section construction for easy service accessibility.
|
|
Backup Control & Manual Foot Pump
|
Back up control on the top side of the column can be actuated at any time and will allow table operation in the event of primary hand controller malfunction. The movements can also be adjusted by a manual foot pump when the motor pump fails or the rechargeable batteries die.
|
Models & Technical Specifications
|
Ultima Model
Technical Data
|
ST-1701 | ST-1702 | ST-1751 | ST-1752 | ST-1501 | ST-1502 | ST-1551 | ST-1552 |
|
Table Top, radiolucent
|
Head, Back, Hip, Solid Leg | Head, Back, Hip, Light Two-piece Legs | Head, Back, Hip, Light One-piece Leg | Head, Back, Hip, Light Two-piece Legs | Head, Back, Hip, Solid Leg | Head, Back, Hip, Two-piece Legs | Head, Back, Hip, Light One-piece Leg | Head, Back, Hip, Light Two-piece Legs |
|
Table Length
|
81” (2060mm) |
83.5” (2120mm) | 81” (2060mm) |
83.5” (2120mm) | 81” (2060mm) |
83.5” (2120mm) | 81” (2060mm) |
83.5” (2120mm) |
|
Table Width (w/o side rails)
|
20.5” (520mm) | |||||||
|
Table Width (w/ side rails)
|
22.6” (575mm) | |||||||
|
Table Height, electrohydraulic
|
27.6” to 43.3” (700 to 1100 mm) |
22.8” to 38.6” (580 mm to 980 mm) |
||||||
|
Longitudinal Slide (Head/Foot), electrohydraulic
|
- |
18” (460mm) Total; 8” (200mm) to Head, 10” (260mm) to Foot
|
- |
18” (460mm) Total; 8” (200mm) to Head, 10” (260mm) to Foot
|
||||
|
Patient Weight Capacity
|
1000lb (454 Kg) patient support, including raise/lower (centered on the column); 800lb (363 Kg) full articulation, including slide; 500lb (227 Kg) full articulation, including reverse patient orientation
|
|||||||
|
Trend./R. Trend., electrohydraulic
|
30°/30° | |||||||
| Lateral Tilting (left/right), electrohydraulic |
20°/20°
|
|||||||
| Head (up/down), gas spring assisted |
90°/90°
|
|||||||
| Back, electrohydraulic |
80°/40°
|
|||||||
| Leg Section (up/down), electric-powered, detachable | 80°/ 105° | - | - | - | 80°/ 105° | - | - | - |
| Leg Section (up/down), gas spring assisted, detachable | - | 50°/90° | 50°/90° | 50°/90° | - | 50°/90° | 50°/90° | 50°/90° |
| Leg Section (Open, 2 pieces), mechanical | - | 0°~140° | - | 0°~140° | - | 0°~140° | - | 0°~140° |
| Flex/Reflex, electrohydraulic | 220°/110° | |||||||
| Kidney Elevator, electrohydraulic | 4" (100 mm) | |||||||
| base Size (L x W) |
44.8" x 20.9" (1140 x 530 mm)
|
|||||||
| Battery operation | Yes | |||||||
| Foot Pump operation as mechanical override |
Yes
|
|||||||
| Swivel Castor Diameter |
4" (100 mm)
|
|||||||
| Floor Lock, electrohydraulic | Yes | |||||||
| Voltage Range | 100V / 240VAC | |||||||
