REF
HF-2900
Dimensions
W330 x D175 x H 140 mm
Weight
2.35 kg (W/O chamber fitted)
Electrical Power
(1) Supply voltage: 230±23V 1.2A (max. 3.2A) 115±12V 1.6A (max. 2.2A)
(2) Supply frequency: 50~60Hz
(3) Heater wire capacity: 60W max
(4) Heater plate capacity: 150W, 110˚C max
Heater Plate Overheat
Cutoff: 115±3˚C
Warm-up Time
10 minutes to 30˚C airway
30 minutes to 37˚C airway
Flow Setting Range
Adult Mode: 15~50 L/min step=5 l/min
Infant Mode: 5~15 L/min step=1 l/min
Temperature Control
(1) Airway 31˚C (Setting Range 31˚C~37˚C)
(2) Chamber 31˚C (Setting Range 31˚C~37˚C)
Oxygen % Measure
21~100%
SpO2 Measure
35~100%
HR Measure
35~250 BPM
Alarm Parameters
(1) Airway: High alarm / Low alarm
(2) Chamber: High alarm / Low alarm
(3) SpO2: High alarm / Low alarm
Recommended Ambient Temp
18~28˚C
Standards
(1) IEC/EN 60601-1, IEC/EN 60601-1-2
(2) ISO 8185:1997
Package
1 set per carton
Carton: L40 x W26 x H29 cm
