| ENGINE |
引擎 |
|
| Type |
引擎型式 |
二行程單缸強制氣冷 2-stroke, Single cylinder, Forced-air-cooled |
| Displacement |
排氣量 |
49.3 cc |
| Bore x stroke |
缸徑×行程 |
40mm × 39.2mm |
| Compression ratio |
壓縮比 |
6.8 : 1 |
| Max. power |
最大馬力 |
2.7 kW at 5800 rpm |
| Max. torque |
最大扭力 |
4.5 Nm at 5700 rpm |
| Lubrication |
潤滑方式 |
機油pump自動預混式 Pump for automatically oil-fuel mixing |
| Carburetion |
燃料供給 |
Mikuni VM 16, 2-stroke |
| Ignition |
點火型式 |
電子點火 C.D.I. |
| Starting system |
起動方式 |
電動/腳踩 Electric motor and kick start |
| Clutch type |
離合器型式 |
離心式自動離合器 Centrifugal clutch |
| Transmission |
傳動方式 |
無段自動變速Automatic (C.V.T system) |
| Final drive system |
動力輸出方式 |
鏈條傳動二輪驅動 Chain drive; 2WD |
| CHASSIS |
底盤 |
|
| Frame |
車架 |
鋼管 Tube |
| Front suspension |
前懸吊系統 |
雙避震器及A臂 Dual hydraulic shock, Single A-arm |
| Front wheel travel |
前輪行程 |
70 mm |
| Rear suspension |
後懸吊系統 |
單避震器懸臂式後叉 Single hydraulic shock, Unit swing arm |
| Rear wheel travel |
後輪行程 |
70 mm |
| Front brake |
前輪煞車 |
雙機械轂煞 Dual mechanical drum |
| Rear brake |
後輪煞車 |
單機械轂煞 Single mechanical drum |
| Combined brake |
四輪煞車 |
N/A |
| Parking device |
駐車系統 |
後輪轂煞駐車鈕 Mechanical brake lock on rear drum |
| Front tire |
前輪規格 |
145 × 70-6 |
| Rear tire |
後輪規格 |
15 × 6-6 |
| DIMENSIONS |
尺寸 |
|
| Overall length |
車長 |
1,275 mm |
| Overall width |
車寬 |
800 mm |
| Overall height |
車高 |
879 mm |
| Seat height |
座墊高度 |
550 mm |
| Wheelbase |
前後軸距 |
745 mm |
| Max. permissible load |
最大載重 |
40 kg |
| Number of seats |
乘坐人數 |
1人 1 Persons |
| Ground clearance |
最小離地高 |
75 mm |
| Dry weight |
淨重 |
77 kg |
| Fuel tank capacity |
汽油箱容量 |
3.4 liters |
