| ENGINE |
引擎 |
|
| Type |
引擎型式 |
四行程單缸平衡軸4-stroke, Single cylinder with balance gear shaft |
| Displacement |
排氣量 |
346.4 cc |
| Bore x stroke |
缸徑×行程 |
82 mmX65.6 mm |
| Compression ratio |
壓縮比 |
10.6:1 |
| Max. power |
最大馬力 |
13.6 kW @ 7250 rpm |
| Max. torque |
最大扭力 |
21.5 Nm @ 4500 rpm |
| Lubrication |
潤滑方式 |
Wet sump, Oil pump pressurized |
| Carburetion |
燃料供給 |
Keihin CVK36 |
| Ignition |
點火型式 |
CDI |
| Starting system |
起動方式 |
Electric motor and recoil |
| Clutch type |
離合器型式 |
Automatic, Dry centrifugal clutch |
| Transmission |
傳動方式 |
CVT |
| Final drive system |
動力輸出方式 |
軸傳動Shaft drive二輪驅動 2WD |
| CHASSIS |
底盤 |
|
|
|
|
|
| frame |
車架 |
鋼管 Tube |
| Front suspension |
前懸吊系統 |
雙避震器雙A臂, 178 mm行程 Dual hydraulic shock, Double wishbone ; 178 mm travel |
| Rear suspension |
後懸吊系統 |
單避震器懸臂式後叉, 165 mm行程, Single hydraulic shock, Unit swing arm ; 165 mm travel |
| Front brake |
前輪煞車 |
雙油壓碟煞 Dual hydraulic discs |
| Rear brake |
後輪煞車 |
單油壓碟煞 Single hydraulic disc |
| Combined brake |
四輪煞車 |
腳踩踏板 Foot pedal |
| Parking device |
駐車系統 |
後輪機械碟煞 Mechanical brake lock on rear disc |
| Front tire |
前輪規格 |
23 × 7-10 |
| Rear tire |
後輪規格 |
23 × 10-10 |
| DIMENSIONS |
尺寸 |
|
|
|
|
|
| Overall length |
車長 |
2012 mm |
| Overall width |
車寬 |
1090mm |
| Overall height |
車高 |
1170 mm |
| Seat height |
座墊高度 |
830 mm |
| Wheelbase |
前後軸距 |
1,260 mm |
| Ground clearance |
最小離地高 |
220 mm |
| Number of seats |
乘坐人數 |
2人 2 Persons |
| Dry weight |
淨重 |
289 kg |
| CAPACITY |
負載能力 |
|
| Fuel tank capacity |
汽油箱容量 |
12.7 liters |
| Rack capacity |
載貨架荷重 |
後 Rear: 30 kg ; 前 Front: 20kg |
| Cargo bed capacity |
載貨箱荷重 |
N/A |
| Towing capacity |
扥車荷重 |
139 kg |
| Max. loading capacity |
最大載重 |
180 kg |
