T25-RS232, TCP/IP, Embedded alarm clock, 3,000 fingerprint templates
. New version of North Korean algorithms with dependability and accuracy, identification speed obviously improved, process 3,000 fingerprints, no matter good or poor, within 0. 7 second.
. Built in embedded standalone module (ZKS710) with high performance SAMSUNG 32 bit X-scale CPU, big capacity FLASH and CMOS chips, it is easy to integrate with various systems.
. Alarm clock function for giving the correct time
. Be equipped with system of calendar which is on an equal footing with PC.
. Sensor with quality image, accepts dry, wet fingers.
. Support 360-degree rotation identification, easy to use.
. Adjust image distortion, assure fingerprint matching consistency. . Accept ODM or OEM, providing system local voice, menu language, software analysis, casing-making.
. It is a good option for enterprise / factory / office / bank use.
Technical Parameters:
Fingerprint capacity: 3,000
Transaction Storage: 80, 000
Period of data: Keep data for 3 years when no current.
Collecting rate: Port rate (9600BPS, 19200BPS, 38400BPS)
Verification mode: 1: N
FAR: <0. 0001%
FRR: <0. 01%
Response time: <0. 7 second
Alarm clock: embedded alarm clock
Communication: RS232/485, TCP/IP
The capacity of connecting net: 31 units (RS485 mode), 255 units (TCP/IP)
Communication: RS232/485, TCP/IP
Show: Time, ID number, Name
Language: English, French, Spanish, Czech, Indonesian, Portuguese, Turkish and so on
Working mode: Time & attendance, standalone, can working persistently
Time & Attendance mode: Fingerprint and password
Save function: Turn off device automatically for saving
Size: 188*130*58mm
Power: DC9V, 1A (AC 100V to 240 V, 50 to 60 Hz)
Warranty of period: 24 months
Temperature and humidity: 0 - 45, 20%-80%
Applications: Small office and slap-up sites and so on
Option: USB, Proximity or Mifare card reader, Build- in backup battery
