Aluminum
3D Aluminum forged top tube with hinge.
Alloy fork, Cr-Mo stem 185mm stem 1.1/8.
Product Specifications
Component:
Bar: Aluminum 580mm. Black Anodized. 3 degree.
Stem: OPX5.0, AL adjustable stem W/OPC folding box.
Grip: Kraton Rubber GEL/BK, 148mm/148mm.
Saddle: Vinyl top w/VELO logo, steel rail silver.
Seatpost: Al 6061, D: 30.4mm, L: 400mm.
Pedal: VP-80 Folding Pedals w/BS REF, AL, Silver.
Drivetrain:
F/derailleur: nil.
R/derailleur: SHIMANO RD-TX35, 7-speed SIS rear index shifting.
Freewheel: SHIMANO, MF-TZ21, 7-SPD 14-28T Multiple Freewheel.
Chainwheel: 3/32" × 52T × 170mm AL Forged Crank BK, Chainring AL SILVER w/CNC chain guard.
Shifting lever: SHIMANO SL-TX50-7R, 7-SP Right hand only.
Chain:KMC Z50, 1/2 × 3/32, Silver/Silver, 116L
Brake:
F/R brake: Tektro 837ALF/R V-brake, Alloy Melt forget, BK.
Levers: Tektro EL520-RS, Sensor control design.
Wheelset:
F/Hub: Alloy.
R/Hub: AL SILVER 14G × 36H × 135mm, 7-SPEED w/skewer.
Rim: AL 20" × 14G × 36H, BED, double chamber, A/V, CNC side walls 451m/m.
Spoke: 14G STAINLESS STEEL.
Electric System
MOTOR： Center Bottom Bracket Motor
Rated power: 200W, Weight 4 Kg.
Controller： Type: Power Assisted.
Pedal Assistance Mode w/4 levels power.
Battery： Type: Lithium ion battery
Working Voltage: 24V
Capacity : 10 Ah / Weight 2 kg
Cycle Life (80%)> 500 cycles
Charging time: 5 hrs (normal)
Charger： Input: 110/230 VAC
Output: 29.4V, 2A
