Aluminum
3D Aluminum forged top tube with hinge.
CRMO steel fork.
Product Specifications
Component:
Bar: Aluminum 6061, T6.
Stem: OPX5.1, foldable and extendable.
Grip: VELO, Kraton rubber.
Saddle: Vinyl top, steel rail, silver.
Seatpost: Al 6061, D: 30.4mm, L: 580mm.
Pedal: VP, foldable.
Drivetrain:
F/derailleur: nil.
R/derailleur: SHIMANO RD-TX5, 7-speed SIS rear index shifting.
Freewheel: SHIMANO, MF-TZ21, 7-SPD 14-28T Multiple Freewheel.
Chainwheel: 3/32" × 48T × 170mm AL Forged Crank BK, Chainring AL SILVER w/double chain guard bk, steel.
Shifting lever: SHIMANO SL-TX60-7R, 7-SP Right hand only.
Chain:KMC Z50, 1/2 × 3/32, Silver/Silver, 116L
Brake:
F/R brake: Tektro 837AL V-brake.
Levers: Tektro TS-374AFR.
Wheelset:
F/Hub: Alloy.
R/Hub: Alloy + 7-sp cassette.
Rim: Al 6061, T6, double chamber.
Spoke: 14G STAINLESS STEEL.
Tyre & Tube: Kenta K-193, 20 × 1.5, A/V. 22TPI.
Electric System
MOTOR： Front Hub Motor
Rated power: 250W, Brushless.
Controller： Type: Power Assisted.
Pedelec Mode.
Maximum speed: 25km/h.
Travel rage: 50 - 75 Km.
Programmable multi function electric cycle computer with data recording & mode select
Battery： Type: Lithium ion battery
Working Voltage: 36V
Capacity : 9 Ah
Cycle Life (80%)> 500 cycles
Charging time: 5 hrs (normal)
Charger： Input: 100/240V~1.2A
Output: 42.0V, 1.35A
