v Fully automatic electric hydraulic control system.
v The memory device is built-in the elevation function. It can elevate while the memory up/down point automatically. (SG-520 only)
v The memory device is built-in the elevation and back section function. It can be moved while the memories up/down point automatically. (SG-510 only)
v When the special position is needed, you can touch the foot control switch to adjust the back section up/down; table top up/down; and seat section up/down. (SG-510 & SG-520 & SG-530 only)
|
Model No. |
SG-510 |
|
Table Top |
55 (W) X 120 (L) cm |
|
55 (W) X 175 (L) cm With Auxiliary Table |
|
|
Elevation |
600 ~ 850 mm (Without mattress) |
|
Maximum high/low can be |
|
|
Back / Break |
-15o ~ +60o |
|
Waist / Break |
0o TO +20o |
|
Power Supply |
110V or 220V/240V 50/60HZ |
|
Standard Accessories |
1. Screen 2. Arm Board 1 PC. 3. Leg Crutches With Clamps 1 PR. 4. Forceps Cups 1 PC. 5. Foot Switch 1 SET 6. Power Cord 1 PC. 7. Contamination Basin 1 PC. 8. Hip Pad (Water Proof) 1 PC. |
|
Optional Accessories |
Waist Side Handle W/Clamp 1 PR. |
|
Delivery Tray 1 SET |
|
|
Funnel & Contamination Bucket With Tube 1 SET |
|
|
Extension Board (Leg Support) 1 SET |
|
|
Leg Crutch Supporter With Slipper W/Clamp 1 PR. |
*Complies with CE requirements as per 93/42/EEC Medical Device Directive
*Sturdy reserves the right to improve the equipment as shown without prior notice.*
