Dimensions and weight
Overall length 1960mm
Overall width 680mm
Overall height 1150mm
Wheelbase 350mm
Minimum over ground space 140mm
Net weight 110kg
Engine Type
mono cylinder, 4 strokes, reinforced wind cooling
Cylinder number 1
Concentration ration 10.5:1
Cylinder diameter and stroke 52.4��57.8mm
Cylinder working capacity 124.6ml
Clutch dry, automatic centrifugal
Speed change mode stepless speed change
Deceleration ratio 8.6
Ignition mode CDI
Minimum stable rotation speed 1900r/min
Nominated power rate and corresponding rotation
Electrical system Battery AH/12V
Headlight 35W/35W/12V
Turning indicator 10W/12V
Taillight 5W/15W/12V
Instrument light 3W/12V
Horn 12V/1.5A
Fuse 6A/50A
Gas and machine oil Gas Vehicle use LPG
Gas tank capacity 5L
Gas tank filling limit 4L
Engine machine oil Summer 15W/40
Winter 5W/30
Capacity 800ml
Gearbox machine oil 20# machine oil
Capacity 100ml
Tyre specs 3.50-10
Tyre air pressure (front/ rear)200/225
Braking mode (front/ rear)disc/ drum
Braking operation mode (front/ rear) Hand/ foot
Felly type (front/ rear)Aluminum alloy
