Applications: For charging & discharging use, cable to panel solution

Advantages
• Quick lock
• Small and compact
• Poka-yoke design on contact surface
• IP67 robust overmolded type
• Stable connection in vibrating environment
• RoHS and REACH compliant

Specifications



Mating Cycle：100 Cycles	Voltage Rating：48V AC / 60V DC	Operating  Temperature：-25°C to 80°C
Wire Processing：Solder	Current Rating：2A	IP Rating：IP66
Wire Gauge：26AWG / 0.12mm²	Withstand Voltage：500V AC	Salt Spray：5% Nacl, 48H
	Insulation Resistance：10MΩ at DC 500V	Flammability Rating：UL94 V-0 (Plastic Material)
